Directional Valves

Products

Showing all 19 products

• Directional ValvesTHM – HM10 Series – Monoblock Directional Control ValveThe THM HM10 Series Monoblock Directional Control Valve is a compact hydraulic valve for open and closed center systems, controlling actuators, cylinders and motors. It has a nominal pressure of 20 MPa, maximum pressure of 25 MPa and maximum flow rate of 120 L/min.View details
• Directional ValvesDirectional Valve -Series Solenoid -WE(26)…(QMBG24) SeriesSolenoid directional valve with spool position monitoring, in sizes NG6 and NG10, for flow control in hydraulic systems.View details
• Directional ValvesTHM – WEMM – Directional ValveThe THM WEMM Directional Valve is a solenoid operated directional valve with an emergency handle. It is available in sizes 6 to 10, with a maximum working pressure up to 350 bar and a maximum working flow rate of 120 L/min.View details
• Directional ValvesTHM – DCT/DCG – Cam operated Directional Control valvesThese cam operated directional control valves shift the direction of oil flow by depressing the spool via a cam. They are available in sizes 01 and 03 with flows of 30 and 100 l/min and maximum pressures of 210 and 250 bar.View details
• Directional ValvesTHM – Z50 – Solenoid directional control valveTHM Z50 solenoid directional control valve features 1 to 6 spools, max flow 50 Lpm, max pressure 315 Bar, with built-in check and relief valves.View details
• Directional ValvesTHM – DCV – Monoblock Directional Control ValveThe THM DCV Monoblock Directional Control Valve is designed for high-pressure hydraulic systems such as drilling machines and sanitation. It offers manual, joystick, cable, pneumatic, solenoid, electro-pneumatic, and electro-hydraulic control types.View details
• Directional ValvesTHM – SD8 – Directional control valveThe THM SD8 is a sectional directional control valve for open and closed center hydraulic systems. It handles max pressure up to 315 bar and max flow up to 90 l/min.View details
• Directional ValvesTHM – SD4 – Directional control valveThe THM SD4 is a monoblock directional control valve with a flow of 45 Lpm and operating pressure of 250 bar. It has one section for open center and closed center hydraulic systems.View details
• Directional ValvesTHM – WE6/10 – Directional control valveThe THM 4WE6 or 10 is a solenoid operated directional spool valve that controls start, stop and direction of flow. It is available in 4/3 and 4/2 configurations with wet pin DC and AC solenoids.View details
• Directional ValvesTHM – 4WH/4WEH – Directional control valveTHM 4WH/4WEH directional control valves are pilot or externally pilot operated 4/2 and 4/3-way valves for controlling fluid flow direction.View details
• Directional ValvesTHM – P120 Monoblock – Directional valveThe THM P120 monoblock directional valve controls the flow of working fluid between pumps, consumers and tanks in mobile hydraulic systems.View details
• Directional ValvesTHM – LC 2-way Cartridge Valve – Directional ValvesTHM LC 2-way cartridge valve for directional control, available in sizes 16 to 63. It features a valve poppet with or without damping nose and multiple control cover options.View details
• THMDirectional ValvesTHM – S4WE6 Series – Directional ValvesThe THM S4WE6 Series is a line of directional valves.View details
• Directional ValvesTHM – LFV Valve with Spool Position Monitoring – Directional ValvesTHM LFV is a 2-way cartridge directional valve with spool position monitoring, providing feedback via an inductive position switch. If the switch reports an error signal, the equipment stops immediately to ensure operator safety.View details
• Directional ValvesTHM – Z-TVC Pre-fill Valve – Directional ValvesThe Z-TVC pre-fill valve is a hydraulic pilot-operated check valve of sandwich plate design for flange connections. It is available with or without de-compression and is made from high grade casting.View details
• Directional ValvesTHM – 23QDF-Ball type solenoid valve – Directional valvesTHM 23QDF ball type solenoid valves are directional valves for leak-free pilot control in two-way plug-in valve hydraulic systems. They use a precision steel ball valve core and handle pressures up to 315 bar.View details
• Directional ValvesTHM – Z4WE6….3XT – Directional ValvesTHM Z4WE6 directional valves are 4/2 way isolator spool valves with wet pin AC or DC solenoids. They are sandwich plate valves for size 6 with a maximum working pressure of 315 bar and flow up to 40 L/min.View details
• Directional ValvesTHM -P80 Monoblock – Directional valveTHM-P80 Monoblock directional valve controls oil flow between pump and cylinder or hydro-motor in hydraulic systems. It is available with 1 to 6 spools and a maximum pressure of 250 bar.View details
• Directional ValvesTHM – P40 Monoblock – Directional valveTHM P40 Monoblock is a manually or mechanically controlled hydraulic directional control valve designed for distribution and control of oil flow between pump and cylinder or hydro-motor. It is manufactured with 1 to 6 spools and nominal pressure of 210 bar.View details
